TD-3
Part #1169256 09/2008
CHAMELEON TRADE DOOR
ITEM
NO
MODEL NUMBER 721 821
HARDWARE
DESCRIPTION QTY
REQ
PART NO. PART NO.
1 DOOR WELD 1 1123712 1123713
2 SIGN FACE 1 ** **
3 SIGN CAP 2 1114341 1114341-1 K
4 SIGN TRIM, VTL, RIGHT, 72” 1 1143505 1143505-1 K
5 SIGN TRIM, VTL, LEFT, 72” 1 1143516 1143516-1 K
6 BEZEL, CONSUMER INTEFACE 1 1143346 1143346 D
7 TRIM EYELET, CURVE 1 388271 388271 D
8 BUTTON ASY, ROUND, CHAMELEON 8 1149374 1149374
9 PLASTIC NUT 8 1073538 1073538
10 SELECTION SWITCH 8 368299 368299
11 BRACKET, SIGN FACE 2 1149404 1149404
12 BALLAST 1 1127052 1127052 Y
13 DOOR ROLLER BRACKET 1 1120552 1120552 V802196
14 DOOR ROLLER 1 1120388 1120388 V802162
15 BUSHING HINGE 1 388094 388094
16 RAIN GUARD 1 2000848 2000848 AE
17 DOOR GUARD 1 2010131 2009503 R,Y
18 LOCK ASSEMBLY (SEE PG 8 - PG 9) 1 ~ ~
19 COIN RETURN BUTTON 1 1050473 1050473
20 COVER, DBV (OPTIONAL) 1 1144557 1144557 S
21 LENS, DISPLAY-BLUE 1 1121103 1121103
