TD-8
Part #1169256 09/2008
DESCRIPTION QTY
REQ
PART NO.
ERROR CODE LABEL, VEC 12.1 1 1123715
PROGRAMMING LABEL, VEC 12.1 1 1123343
WIRING DIAGRAM LABEL, VEC 12.1/12.2 1 1124295
PRODUCT SET UP, V21 1 1124035
SPACE TO SALES, VEC 12.1 1 1122286
INNER DOOR LABEL 1 1008323-1
V21 TRADE INNER DOOR
V21 TRADE INNER DOOR LABELS - NOT SHOWN
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-16
ITEM
NO
MODEL NUMBER 721 821
DESCRIPTION
QTY
REQ PART NO. PART NO.
1 INNER DOOR ASSEMBLY 1 134302-103 134302-104
2 RAIN SEAL, INNER DOOR, 7” 1 1111732-2 1111732-2
3 INNER DOOR SEAL 1 1075678 1075678-1
4 UPPER PRODUCT RETAINER ASSEMBLY 1 1125206-1 1125206-2
5 UPPER PRODUCT RETAINER 1 1124285 1124285-1
6 SHORT CLIP ASSEMBLY 9 1125261 1125261
7 LONG CLIP ASSEMBLY 1 1125262 1125263
8 INNER DOOR HINGE, FEMALE 2 1121286 1121286
9 HINGE PIN 1 389985 389985
10 REVERSABLE VEND FLAP 1 1013076 1013076
11 INNER DOOR EYELET 1 387273 387273
12 GROMMET 1 388090 388090
13 INNER DOOR LATCH 1 1121711 1121711
14 INNER DOOR LATCH BRACKET 1 1121712 1121712
