T-5
Part #1169256 09/2008
Error DESCRIPTION OF ERROR
CODE
CHECKING METHOD Corrective Action
Usnn Selection switch skipped - switch
nn unassigned and a higher
number switch is assigned.
Switch is assigned.
Coin Changer
CC Changer communication error - no
changer communication for more
than 2 seconds.
1) Check that red light is fl ashing on
control board.
If light is not fl ashing, there is no
power to board. Check and replug
any unplugged connections.
If fuse is blown replace it.
Replace transformer.
2) Defective acceptor. Replace acceptor.
TtS Tube sensor is defective --
reported by changer .
Check changer tubes for blockage. Clear tube blockage. If no
blockage is found, replace
changer.
IC Changer inlet chute blocked - no
coins sensed for over 96 hours by
the changer.
Check inlet chute for blockage. Drop
coins to test acceptance. Manually
clear the error.
Clear inlet chute blockage. If no
blockage found, replace changer.
If acceptance rate is acceptable,
system is OK. If acceptance rate
is low or changer will not accept
coins, replace changer.
tJ Tube pay out jam -- reported by
changer.
Check changer tubes and payout for
blockage.
Clear blockage, if found. If
no blockage is found, replace
changer.
CrCH Changer check sum incorrect --
reported by changer.
Turn power switch off, wait at least
fi ve seconds, then turn on. Manually
clear the error.
If error does not clear, replace
changer/acceptor.
Replace changer.
EE Excessive escrow requests --
more than 255 requests since the
last coin was sensed.
Check escrow lever and associated
mechanisms.
Manually clear the lever and error.
Close door then reopen. Check to
see if error still occurs.
Replace changer/acceptor.
nJ Coin jam - reported by changer. Check changer/acceptor for jammed
coins or other obstructions.
If no obstructions are apparent,
replace changer/acceptor.
LA Low acceptance rate -- coin
acceptance has fallen below 80%.
Check changer/acceptor for
obstructions or dirt.
If no obstructions are apparent,
and acceptance appears to be
OK, this may be an indication of
cheating attempts.
Drop coins to test acceptance. If no obstructions are apparent
and coins do not accept, or
acceptance rate is poor, replace
changer/acceptor.
diS Disconnected acceptor -- indicates
that an acceptor is unplugged.
Check coin mechanism plugs. Check
for faulty harness wiring (see wiring
diagram for circuit).
Correct connections.
rout Coin routing - indicates a coin was
routed incorrectly.
Verify changer set-up using
manufacturer’s recommendations.
If acceptor was set up correctly,
replace changer.
