Vendo VUE 30 User Manual

If 'Y' Motor has not returned to the home
position, check to see if the hand is jammed on
a tray or other item in the cabinet.
Clear jam.
POWER DOWN, wait 5 seconds then POWER ON.
If hand (Y Motor) goes back home after 'Auto
Recovery', run 'Y' Motor test in Test Motors.
Complete a test vend cycle.
If hand does not go home in 'Y', replace 'Y' Motor.
If 'Y' Motor has returned to the home position,
hand jammed, but recovered, check product
positions to determine if any display 'sold out'
with product still in a column.
Complete a test vend cycle of sold out products.
If hand hits tray in Y, perform a Calibration Discovery
2.
Perform System Check, see X-Motor Jam. POWER DOWN.
Replace fuse(s) if necessary.
POWER ON.
Complete a test vend cycle.
If unit is extended in 'Z' check 'Z' Housing
Ribbon Cable (within the hand) to be sure it is
plugged in.
Please refer to Diagram 1A
POWER DOWN.
Plug in 'Z' Housing Ribbon Cable.
POWER ON.
If hand goes back home after auto recovery, run 'Z'
Motor Test in Test Motors.
Complete a test vend cycle.
If a product is in the hand, perform a visual
check to see if the product is stopping the hand
from closing around it.
Remove product from hand.
POWER DOWN, wait 5 seconds. POWER ON. If hand
goes back home after auto recovery, run 'Z' Motor Test
in Test Motors. Complete a test vend cycle.
Z-motor Jam Z' Motor portion of
vending mechanism
did not start or
complete.
If unit has returned to the home position, hand
jammed, but rec
overed, check product
positions to determine if any display 'sold out'
with product still in a column.
Complete a test vend cycle of sold out products.
If hand hits the tray front, run a Calibration Discovery
2.
If hand jams on center gate, reduce 'Z' Product
Position by 3 encodings in 'Calibration'. Please call
Tech Services at: 1-800-344-7216 for information
when attempting this function.
See X-Motor Jam information listed on prior
page.
POWER DOWN.Replace fuse(s) if necessary.
POWER ON.Complete a test vend cycle.
Clamp-motor Jam
Clamp Motor did not
start or complete its
cycle.
Inspect clamp fingers to see if they are partially
open only.
Clamp motor has failed. Replace clamp motor.
