HE250 - Installation and Operation Manual 39
6.3.2 Minimum Hearth Extension Requirements
The hearth extension floor area must extend at least 16" (406 mm) in front of the hearth (A) and at least
8" (203 mm) on each side of the door opening (D). The joint between the hearth extension and the fireplace
hearth needs to be made of non-combustible material such as sheet metal (not included).
CLEARANCES
A
16" (406 mm)
B
41.5" (1054 mm)
C
8" (203 mm)
