90 HE250 - Installation and Operation Manual
#
Item
Description
Qty
38
44084
RHEOSTAT WITHOUT NUT AND FLAT WASHER
1
39
PL63881
RHEOSTAT BRACKET
1
40
44087
RHEOSTAT NUT
1
41
44085
RHEOSTAT KNOB
1
42
44091
ROCKER SWITCH 2 POSITION MSR-8
1
43
44122
DOUBLE CAGE BLOWER 176 CFM (CLASS H)
1
44
SE45704
VENTIS INSTRUCTION MANUAL KIT
1
45
AC05959
METALLIC BLACK STOVE PAINT - 342 g (12oz) AEROSOL
1
46
AC01340
FORCED AIR DISTRIBUTION KIT 300 CFM
1
47
44142
BLOWER 6'' 300 CFM
1
48
44125
FORCED AIR DISTRIBUTION KIT PC CARD
1
49
22152
LEFT REFRACTORY
1
50
22151
REFRACTORY RIGHT STONE
1
51
22150
REAR REFRACTORY
1
52
22141
FLOOR REFRACTORY SLAB
1
53
PL53144
LOG HOLDER
1
54
30506
SCREW PAN TORX TYPE F 1/4-20 X 1" BLACK
2
55
PL53145
REFRACTORY BRICK PANEL RETAINER
2
56
PL53132
FRONT SECONDARY AIR TUBE
1
57
PL53133
FRONT CENTER SECONDARY AIR TUBE
1
58
PL53134
REAR CENTER SECONDARY AIR TUBE
1
59
PL53135
REAR SECONDARY AIR TUBE
1
60
SE36250
STAINLESS STEEL COTTER PIN 1/8" X 1 1/2" (12 UNITS)
4
61
30026
THREAD CUTTING SCREW 10-24 F 5/8" HEX WASHER HEAD
5
62
PL53041
REAR REINFORCEMENT
1
63
21296
C-CAST BAFFLE 24 3/16" X 20 5/8" X 14 3/4" X 1 1/4"
1
64
21148
BAFFLE INSULATION 24 3/16" X 20 5/8" X 14 3/4" X 1"
1
65
PL34026
BAFFLE INSULATION WEIGHT
1
66
AC01389
HOT AIR GRAVITY DISTRIBUTION KIT - MODERN WITH ADJUSTABLE PIPES
1
67
AC01375
HOT AIR GRAVITY DISTRIBUTION KIT - TRADITIONAL
1
68
49066
90° X 8" 26Ga. GALVANISED ELBOW
2
69
30640
GAKLVANISED BOX FOR HOT AIR GRAVITY DISTRIBUTION KIT 8"
2
70
30540
HOT AIR GRAVITY DISTRIBUTION KIT GRILL
2
71
PL53026
AIR INTAKE BOX COVER
1
72
30154
BLACK SCREW #10 X 5/8" QUADREX #2 TYPE A
4
73
SE66579
REPLACEMENT HE250 HANDLE KIT
1
