Ventis HE250 - Page 89

HE250 - Installation and Operation Manual 89
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your stove,
please provide the model number and the serial number. We reserve the right to change parts due to
technology upgrade or availability. Contact an authorized dealer to obtain any of these parts. Never use
substitute materials. Use of non-approved parts can result in poor performance and safety hazards.
#
Item
Description
Qty
1
AC01560
RIGID FIRESCREEN
1
2
VBA1510
BLACK DOOR OVERLAY
1
2
VBA1511
PLATED BRUSHED NICKEL DOOR OVERLAY
1
3
SE63887
FP10 BLACK OVERLAY BOLT KIT (6)
1
3
SE63888
FP10 NICKEL OVERLAY BOLT KIT (6)
1
4
30765
WOODEN DOOR HANDLE
1
5
30123
SCREW #8 - 32 X 5/8'' PAN QUADREX ZINC
2
6
30766
WOODEN CAP HANDLE
2
7
SE66583
VENTIS DOOR ASSEMBLY
1
8
30802
SHOWLDER SCREW #10-24 X 1/2"
1
9
30779
PIVOT BUSHING
1
10
PL66579
DOOR LATCH
1
11
30801
BLACK OXIDE SPRING WASHER
1
12
30192
STAR RING #10 X .410-.395" OD - .025-.020" THICK
1
13
30359
HEX NUT #10-24 ZINC
1
14
SE66582
REPLACEMENT GLASS WITH GASKET 13" x 25-3/8"
1
15
AC06400
3/4" (FLAT) X 6' BLACK SELF-ADHESIVE GLASS GASKET
1
16
PL66575
LEFT DOOR HOLDER
2
17
PL66576
DOWN GLASS RETAINER
2
18
30124
SCREW #8 - 32 X 5/16'' TRUSS QUADREX ZINC
10
19
AC06730
SILICONE AND 1'' X 8' BLACK DOOR GASKET KIT
1
20
30060
THREAD-CUTTING SCREW 1/4-20 X 1/2" F HEX STEEL SLOT WASHER C102 ZINC
1
21
30185
17/64" AA TYPE WASHER BLACK
1
22
30187
STAINLESS WASHER ID 17/64" X OD 1/2"
1
23
30556
AIR CONTROL FINISHING TIP
1
24
PL66604
AIR CONTROL MECHANISM
1
25
30472
SPRING 1/2'' OUTSIDE Ø X 3''L
2
26
SE66578
DOOR LOCK ASSEMBLY
1
27
30597
OFFSETTED HINGE PIN
2
28
30117
SOCKET SET SCREW #10-32 X 1/4"
2
29
VBA1500
MODERN STYLE FACEPLATE - METALLIC BLACK
1
30
CVA-AP06
6" STAINLESS STEEL ANCHOR PLATE
1
31
PL63766
HEADER STAND OFF
2
32
PL66500
TOP HEAT SHIELD
1
33
PL53065
REAR SPACER
2
34
PL63768
SIDE REAR SPACER
2
35
PL63767
SHORT SIDE STANDOFF
4
36
44028
CERAMIC THERMODISC F110-20F
1
37
99999
BUILD TO ORDER
1
