76 HE250 - Installation and Operation Manual
APPENDIX 3: INSTALLING THE OPTIONAL DOOR OVERLAY
In order to complete the assembly of your HE250 wood fireplace, you need to install the door overlay. See
figure below for installation instructions:
Position the overlay (A) and on the door frame
and secure from the inside of the door using
the 6 included screws (B) and bolts (C).
To facilitate the installation, do not tighten the
screws until they are all installed.
Note: It is not necessary to remove the glass
or any other component to install the overlay.
