HE250 - Installation and Operation Manual 61
APPENDIX 1: OPTIONAL HEAT DISTRIBUTION SYSTEMS INSTALLATION
Different heat distribution systems can be installed with the HE250:
• Hot air gravity distribution kit - Traditional (AC01375)
• Hot air gravity distribution kit - Modern with adjustable pipes (AC01389)
• Forced air distribution kit
Hot air gravity distribution kit - Traditional (AC01375)
The kit includes:
- 2 x hot air outlets (grilles (A) and frames (B));
- 2 x 90
o
elbows (C);
- 6 x steel brackets (D) with fastening screws (E) and self-tapping screws (F)
Parts not included in the kit:
- 2 x 8” rigid ducting (G)
