HE250 - Installation and Operation Manual 73
APPENDIX 2: BLOWER MAINTENANCE OR REPLACEMENT
1. Open the bottom louver (A).
2. With a short square head screwdriver,
remove the 4 screws (C) holding in
place the heat shield (B).
