Operation - 22
OPERATIONAL CONTROLS
Standard Control Locations
Become familiar with all the controls before you start
the engine and operate the machine.
A. Information Cluster Gauge
B. Warning Alarm (Continuous)
C. Ignition Switch
D. Throttle Lever
E. High/Low Shift Lever
F. Steering Wheel
G. Parking Brake
H. Front Hitch Latch Lever
I. Front Hitch Latch Lever Lock
J. Neutral Assist Lever
K. Auxiliary Hydraulic Quick Couplers
L. PTO Belt Tensioner Rod
M. Primary SDLA Control Lever
N. Secondary SDLA Control Lever
O. PTO Switch
P. Headlight Switch
Q. USB Receptacle
R. Seat Slide Lever
T. Circuit Breaker and Battery Disconnect
U. Seat Prop Plate
V. Seat Latch Strap
W. Weight Transfer Select Lever
Z. Engine Malfunction Indicator Light
M
N
O
P
Q
A
B
C
D
E
W
F
Z
G
H
I
J
K
L
U
V
R
S
T
