Ventrac 4520N - Dimensions; Fluid Capacities and Specifications

SPECIFICATIONS

Dimensions
Wheelbase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114 cm (45 inches)
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .208 cm (82 inches)
Overall Height (top of ROPS bar) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .170 cm (67 inches)
Overall Width (single tires)* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122 cm (48 inches)
Overall Width (dual tires)* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .185 cm (73 inches)
Weight** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 816.5 kg (1,800 pounds)
Venture Products, Inc. reserves the right to change these specications without notice.
*May vary based on the tire size, type, and ination.
**Weight varies based on the engine size, tire options, and optional accessories.

Fluid Type Capacity Filter #1 Filter #2
Engine Oil*
(Power Unit Serial Range
AR1001 - AR12882)
Synthetic 10W-30
%
3.4 liters (3.6 quarts) 13.0267
Engine Oil*
(Power Unit Serial Range
AR12883 - )
Synthetic 10W-30
%
3.7 liters (3.9 quarts) 13.0267
Hydraulic Oil (Front trans-
axle and Reservoir)
HydroTorq XL Synthetic
Hydraulic Oil
11.6 liters (12.3 quarts)
Optional 3-point hitch
12.2 liters (13 quarts)
21.0122
(Suction lter)
21.0124
(Return lter)
Hydraulic Oil (Rear trans-
axle)
HydroTorq XL Synthetic
Hydraulic Oil
4.4 liters (4.6 quarts) - -
Cooling System
50% distilled water and 50%
ethylene glycol antifreeze^
6.6 liters (7 quarts) - -
Fuel System
Unleaded Gasoline
(Max 10% Ethanol)
22.7 liters (6 gallons) 13.0053 -
Grease Lithium Complex NLGI #2
Refer to the Maintenance
Chart
- -
*= Engine oil capacity varies between the serial range listed above due to a change with the engine oil pan.
%
= Use API Classication SL or higher. For optimal engine life and performance, use Ventrac full synthetic engine oil (Part Number 15.0037-1).
^Recommended antifreeze: a low silicate, phosphate free antifreeze (ethylene glycol) containing supplemental coolant additives (SCAs) to inhibit corrosion
and rust.
