Your TV is packaged with the stand and the cabinet separated. Before using the TV, install the
stand as described below, or if you want to mount it to wall, see page 6 for mounting advice; the
wall mount itself is not supplied.
IMPORTANT!
Make sure the TV set is unplugged from the power supply before installing or
removing the stand.
The TV panel may be awkward to install on your own. We recommend you ask
someone to help with installation and/or removal of the stand.
Attaching the stand
Step 1:
Place a soft cushioned material on top of
a flat surface to prevent damaging the
screen panel. Then place the TV monitor
flat on top, with the screen side facing
down, as illustrated in Fig. 3, right.
Step 2:
Fixing,four screws on the stand,
as illustrated in Fig. 4, right.
Step 3:
The stand on the TV, as illustrated in Fig. 5,
below.
Fig. 3
Fig. 4
Fig. 5
