VeriFone V400c Plus - Connecting to ECRs; Connecting to PINpads

SETUP
Connecting Optional Devices
24 V200C AND V400C INSTALLATION GUIDE
Connecting to ECRs
V200c and V400c terminals support electronic cash registers (ECRs).
Figure 12 shows how to make a peripheral connection to the Multi-
Communication port using the MOD 10 RS-232 + USB Multi-Communication
dongle (VPN CBL420-002-01-A)
Figure 12 Sample ECR Connection
Connecting to
PINpads
V200c and V400c terminals also support PIN pad devices.
Figure 13 shows how to connect a PIN pad device to the host USB port on your
V200c and V400c device
Figure 13 Sample PIN pad Connection on Host USB Port
RS232
