VeriFone VX 820 Installation Guide

SETUP
Optional Accessories
20 VX 820 INSTALLATION GUIDE
V
E
R
I
F
O
N
E
C
O
N
F
I
D
E
N
T
IA
L
R
E
V
I
S
I
O
N
A
.
5
Optional
Accessories
These accessories do not come with the standard VX 820 package but can be
used to further enhance the device’s functionality.
Privacy Shield
This figure shows an example of a VX 820 with the privacy shield installed.
Figure 18 Installed Privacy Shield
Stylus and Holder
An stylus with holder can be attached to the VX 820 and used as an alternative
device input method.
To attach the stylus holder, screw it into the back of the VX 820 as shown in the
illustration below:

VeriFone VX 820 Specifications

General

Display	3.5 inch color touchscreen
Connectivity	Ethernet, USB, RS-232
Processor	400 MHz ARM11
Memory	128 MB Flash, 32 MB SDRAM
Card Readers	Magnetic stripe, contactless
Security	PCI PTS approved
Weight	320g
