Vernacare VORTEX AIR - General Assembly Overview

Page | 11
VORTEX AIR Technical Manual
Revision 6- Issued by N. Shields 24/08/2023
3.3. General Assembly
The exploded images of the Vortex Air assembly below should be used for familiarisation with key
components and assemblies.
1
2
3
4
Top Cover
Lid Top
Lid Bottom
Water Tank
5
6
7
8
Deodoriser Tank
PCB
Inverter (motor control)
Power Supply Unit
9
10
11
12
Hopper
Display Membrane
Front Cover
Side Panels
1
2
4
5
6
8
7
9
10
11
12
3
