3.4.1. AC Motor
0.75 KW; 3 Phase; 220-240v 50Hz/ 380-420v 50Hz; IP55; D71 frame size. Rating at peak load 2.6
amps (nominal).
3.4.2. Inverter
AC inverter with either 110v or 230v supply voltage, 230v motor output and utilising current
monitoring.
3.4.3. Pump
0.18kW, 24V DC.- Protected by a 10A fuse.
3.4.4. Water requirements
Inlet supply: Cold water ONLY with flow rate of 8 l/min minimum. Nominal overall usage is 18 litres
(+/- 10%) per (standard) cycle. ¾” BSP connections (male).
3.4.5. Drainage
A 2” inch/ 50mm drain pipe to be connected either directly, or via a swept bend, to a standard
2”in/50mm drain pipe with a 1 in 25 or suitable fall into a soil drain.
