Vernacare VORTEX AIR - AC Motor Wiring Diagram; Electrical Enclosure Diagram

Page | 35
VORTEX AIR Technical Manual
Revision 6- Issued by N. Shields 24/08/2023
5.11. AC Motor Wiring Diagram
Motor wired in Delta for 220v input from the inverter unit.
Ø Ø Ø
W2 U2
V2
U1 V1
W1
1 2 3
5.12. Electrical Enclosure
EMC FILTER
24V DC POWER
SUPPLY
PCB
INVERTER M
L
N
E
24v
0v
0v
24v
Lid Position
Safety Switch
MAINS SUPPLY
1PH 230/110v
RL SD
W
V
U
L3
L2
L1
