EXS
92 User Manual 10H52260UM60 - Rev. 1 - 10/2017
Figure 8-10 Appeara
nce and wiring diagram of cable 2 (UFDRY21SL2)
Figure 8-11 Appearance and wiring dia
gram of cable 3 (UFDRY21SL3)
Installation
Note
Some electronic components on the relay card are sensitive to static electricity. To prevent static electricity from damaging
the relay card, do not touch its electronic components or circuits, also make sure that they do not come into contact with
live parts. Please hold the relay card by its edges when handling or installing it.
1. Set the DIP switch on the relay card.
Skip this step if you do not need to control the UPS switch-on and switch-off functions via the relay card.
The location of the DIP switch is shown in Figure 8-12. It is a
n 8-bit DIP switch. Its factory default setting is shown
in Figure 8-6.
Fig
ure 8-12 DIP switch factory default setting
Bits 1 through 7 are designed for use in the factory, the user is not permitted to change their default settings. Bit 8 is
used to configure the UPS switch-on and switch-off signal input function on the relay card, see Table 8-4 for
instructions on how to set it.
DB25 male (pin-type)
13
25
12
24
11
23
10
22
9
21
8
20
7
19
6
18
5
17
4
16
3
15
2
14
1
X14J7A plug (pin-type)
1
2
3
4
5
6
7
DB25 ma
e
pin-type
X14J7A plug (pin-type)
560 ohm/1W
DB25 male (pin-type)
13
25
12
24
11
23
10
22
9
21
8
20
7
19
6
18
5
17
4
16
3
15
2
14
1
This end is labelled "UPS"
DB25 male (pin-type)
13
25
12
24
11
23
10
22
9
21
8
20
7
19
6
18
5
17
4
16
3
15
2
14
1
This end is labelled 'UPS'
DB25 male (pin-type)
DB25 male (pin-type)
560 ohm/1W
123456
7
8
ON
