Vertiv EXS - Appendix 1 LCD Parameter Settings; LCD Parameter Settings - System, Output, Parallel

EXS
User Manual 10H52260UM60 - Rev. 1 - 10/2017 103
Appendix 1 LCD Parameter Settings
Menu Item Setting range Default setting
System
Auto restart Disable, Enable Enable
Auto restart delay
0
～
999 seconds
10; Single unit only
Guaranteed shut-down Disable, Enable Disable
Remote control Disable, Enable Enable
Remote power on delay
0
～
999 seconds
0
Remote shut-down delay
0
～
999 seconds
0
Redundant NO, YES YES
LBS select Disable, Master, Slave Disable
IT system compatibility Disable, Enable Disable
Dry contact 1 (Output)
Low battery, On bypass, On battery,
UPS fault
Low battery
Dry contact 2 (Output)
Low battery, On bypass, On battery,
UPS fault
UPS fault
Dry contact 3 (Input)
Battery mode shut-down, Any mode
shut-down, Maintain mode
Maintain mode
Dry contact 4 (Input)
Battery mode shut-down, Any mode
shut-down, Maintain mode
Maintain mode
Output
Voltage selection 220V, 230V, 240V 220V
Start-up on bypass Disable, Enable Disable
Frequency selection
Auto, BypEna; Auto, BypDisa;
50Hz, BypDisa; 60Hz, BypDisa
Auto, BypEna
Inverter sync range
±0.5Hz, ±1.0Hz, ±2.0Hz, ±3.0Hz,
±4.0Hz, ±5.0Hz
±3.0Hz
Bypass voltage upper limit +10%, +15%, +20% +20%
Bypass voltage lower limit -10%, -20%, -30%, -40% -40%
Bypass frequency range ±5Hz, ±10Hz ±10Hz
Run mode Normal, ECO mode Normal
ECO voltage range ±5%, ±10%, ±15% ±10% Appear
only
when
the 'Run
mode' is
set to
'ECO
mode'
ECO frequency range ±1Hz, ±2Hz, ±3Hz ±3Hz
ECO requalification time 5, 15, 30 (min) 30
Output phase No. 1 phase, 3 phases 3 phases
Parallel
Voltage selection 220V, 230V, 240V 220V
Frequency selection
Auto, BypEna; Auto, BypDisa;
50Hz, BypDisa; 60Hz, BypDisa
Auto, BypEna
Run mode Normal, ECO mode Normal
Redundant NO, YES YES
System parallel No.
1
～
4
1
Output phase No. 1 phase, 3 phases 3 phases
Sync parallel parameters Button Button
Battery
Shared battery Enable, Disable Disable
Local/Parallel battery total Ah
7
～
3000Ah
External battery cabinet count
Auto test, 0
～
10
Auto test
Low battery time
2
～
30 (min)
2
Battery replaced time YYYY-MM-DD HH:MM:SS 2000-01-01 0:00:00
Battery test interval
Disable, 8 weeks, 12 weeks, 16
weeks
，
20 weeks
，
26 weeks
Disable
