Chapter 8 Options
This section lists the UPS options and provides information about installing and configuring the various options, and
their respective functions.
8.1 List of Options
See Table 8-1 for a list of the UPS options.
Table 8-1 Option list
No. Option name Note Model
1
3-in 1-out copper bar
kit
Site installation EXS 0020kTSB01
2
32-block internal
battery kit (2-group)
Factory installation contains battery cables, trays and
batteries;
Site installation contains battery cables and trays.
Battery string should be user-prepared
EXS 0020kBSI02 (factory
installation, 9Ah battery)
EXS 0020kBSE02 (site
installation)
3
32-block battery
internal kit (4-group)
EXS 0020kBSI04 (factory
installation, 9Ah battery)
EXS 0020kBSE04 (site
installation)
4
Battery temperature
sensor kit
Site installation EXS 0020kBDS02
5
Protective devices for
short circuit withstand
current
Withstand current: 30kA, factory installation EXS 0020kTSB01
6 Relay card UF-DRY410
7 UNITY-DP card IS-UNITY-DP
8 UNITY-LIFE card IS-UNITY-LIFE
9 Paralle cable
1m
3m
10 LBS cable ITA-20k00AL3A02C00L2
11
Backfeed protection
device
Includes backfeed power board, cables, excitation
tripping device; factory installation
EXS 0020kBFP01
8.2 Option Introduction
Internal Battery Kit
VERTIV provides two kind of internal battery kits for the user when UPS internal battery or corresponding kits are
required. Kit A: 32-block internal battery kit (2-group, factory installation), or the required battery cables, battery
trays, screws (site installation); kit A: 32-block internal battery kit (4-group, factory installation), or the required
battery cables, battery trays, screws (site installation).
Table 8-2 Parameters of valve-regulated lead acid batteries
Capacity Dimensions Overall height (H) Container height (h) Length (L) Width (W)
9Ah mm (inch) 98.6±1 (3.88±0.04) 94.3±1 (3.71±0.04) 150.9±2 (5.94±0.08) 64.8±1(2.55±0.04)
4m
10m
ITA-20k00AL3A02C00L
1 ITA-20k00AL3A02CL3
ITA-20k00AL3A02EL1
ITA-20k00AL3A02EL2(only
support 2 units parallel).
12 Intellislot extender kit EXS 0020kTH1AFN01Z5
13
EMC C2 kit
EXS 0020kTH1AFN01Z16.
Extend Intellislot from 1 to 2; factory installation.
