Vertiv Liebert DM Series User Manual

Vertiv™ | Liebert® DM | User Manual 4
Overview
1.2. Model Description
The Liebert® DM air conditioner series is fully-defined by eleven digits, as represented in Table 1-1.
Table 1-1 Liebert DM Model Nomenclature
1 2 3 4 5 6 7 8 9 10 11
D M E 0 7 M C S U A 1
Digit 1,2 Product Model
DM DataMate
Digit 3 Unit
E Indoor Unit
C Outdoor Unit
Digit 4,5 Cooling Capacity kW
0-9 Nominal Cooling Capacity - kW
Digit 6 Power Supply
M 400 V, 3 Ph, 50 Hz
W 230 V, 1 Ph, 50 Hz
Digit 7 Cooling System
C Cooling Only
0 Cooling and Heating
H Cooling and Heating and Humidifying
Digit 8 Fan
S Forward Centrifugal Fan AC Type
0 Backward Centrifugal Fan AC Type
1 EC Fan
Digit 9 Air Discharge
U Upflow
F Downflow
Digit 10 Client Code
A For Asia Pacific Customer
Digit 11 Version
1-9 Design Version
The standard components are represented in ‘Bold Italic’ font in Table 1-1.
• The specification options represented in nomenclature such as Cooling system, Fan and Air discharge are
only applicable to the Indoor unit.
• Power supply of 400 V, 3 Ph, 60 Hz is available on request, contact vertiv representative for details.
• There is no Cooling Only option for 07 kW and 12 kW models.
