Outdoor Fan Speed Controller (Only for 22 kW/27 kW)
6.2. Human-Machine Interface
The fan speed controller realizes the human-machine interface function through the indicators, RS232 serial communication
interface, buttons and digital tube.
• Indicators
There are three indicators on the fan speed controller board as shown in Figure 6-1 and refer Table 6-2 for the indicator
function.
Table 6-2 Indicator Function of Speed Controller Board
Terminal Description Color Status Function
D16
Power
indicator
Green
On CPU circuit has 5 V power supply.
O Fan speed controller board failure.
D22
Run
indicator
Green
On or O Fan speed controller board failure.
1 Hz flashing (slow flash) No alarm, normal operation.
5 Hz flashing (fast flash) There is an alarm or the compressor is stopped.
• RS232 serial communication port
The RS232 serial communication interface provides an interface to the monitoring computer using a factory-defined
protocol, mainly used for factory commissioning and maintenance.
• Button and digital tube
The buttons and the digital tube provide a human-machine interface for on-site maintenance, and can realize the functions
as described in Table 6-3. Refer Section 6.3 for the Human-Machine Interface operation instructions of buttons and digital
tube.
Table 6-3 Button and Digital Tube Function Description
No. Function Description
1
Real-time query of
collected data
Queryable data includes condensing pressure, ambient temperature, SCR
temperature, and output percentage.
2
Real-time query of
active alarm data
Queryable active alarm data includes input phase loss alarm, SCR over
temperature, Fan 1 over temperature, Fan 2 over temperature, pressure sensor
failure, EEPROM read failure, SCR temperature sensor failure and frequency
anomaly.
3
Real-time query of
historical alarm data
Can query the most recently saved 100 historical alarms.
4
Modify configuration
parameters in real time
The modifiable configuration data includes start-up pressure, minimum voltage,
pressure control range, maximum voltage, number of fans, pressure sensor type,
or restore the above parameters to default values.
