Electrical Installation
No. Description No. Description
1 Cable hole in cover 4 Wire clamp
2 Cable hole 5 Cable hole in unit
3 Power input terminal
Figure 3-5 Power Connection of Outdoor Unit (17 kW)
No. Description No. Description
1 Cable hole 3 Power input terminal
2 Fan speed controller 4 Cable clip
Figure 3-6 Power Connection of Outdoor Unit (22 kW/27 kW)
