MODEL EDGE-1500IRT2UXL EDGE-2200IRT2UXL EDGE-3000IRT2UXL EDGE-3000IRT3UXL
Power Rating @ 230V 1500VA / 1350W / 6.7 A 2200VA / 1980W / 9.8A 3000VA / 2700W / 13.3A
High Line Normalto
Buck
220 / 229 / 242 / 253 / 264 VAC
High Line Buck to
Normal
215 / 224 / 237 / 248 / 259 VAC
Low Line Boost1 to
Normal
185 / 192 / 203 / 212 / 221 VAC
Low Line Normalto
Boost1
180 / 187 / 198 / 207 / 216 VAC
Low Line Boost2 to
Boost1
160 / 166 / 176 / 183 / 191 VAC
Low Line Boost1 to
Boost2
155 / 161 / 171 / 178 / 186 VAC
Low Line Battery to
Boost2
155 / 161 / 171 / 178 / 186 VAC
Low Line Boost2 to
Battery
144 / 150 / 158 / 166 / 173 VAC
Frequency Input
Range
45 to 65 Hz
Autodetect 50 / 60 Hz
Battery to Normalcomeback at 50Hz: 47 to 53Hz
Battery to Normalcomeback at 60Hz: 57 to 63Hz
Internal Rear-panel
Input Breaker Rating
10 A 16 A
Input Surge Protection EN61000-4-5; Line to Line: Level 2; Line to Earth: Level 3 Input Power (624J L/N, 624J L/G, 624J N/G)
Input Power
Receptacle
IEC 320 C14 IEC 320 C20
Output
Output Voltages (on
battery)
200 / 208 / 220 / 230 / 240 VAC (230 VAC is factory default)
Output Frequency (on
battery)
Autodetect 50/60 Hz ±1%
Output Receptacles -
not controllable
(3) IEC 320 C13
(3) IEC 320 C13
(1) IEC 320 C19
(6) IEC 320 C13
(1) IEC 320 C19
Output Receptacles -
controllable
(3) IEC 320 C13
Transfer Time Adjustable with Input Waveform Sensitivity setting. See Settings Submenu for details.
Output Waveform (on
Battery)
Pure Sinewave
Table 6.3 Specifications, EDGE-1500IRT2UXL, EDGE-2200IRT2UXL,EDGE-3000IRT2UXL and EDGE-
3000IRT3UXL (continued)
