MODEL
EDGELI-
1500IRT2U
EDGELI-2200IRT2U EDGELI-3000IRT2U
Power Rating @ 230V
1500VA / 1350W /
6.7 A
2200VA / 1980W / 9.8A 3000VA / 2700W /13.3A
Dimensions, D×W×H, in. (mm)
Unit Dimensions, W x D x H, mm 438 x 410 x 86 438 x 510 x 86 438 x 610 x 86
Shipping Dimensions, W x D x H,
mm
550 x 620 x240 565 x 700 x 240 600 x 800 x 240
Weight, lb.(kg)
Unit Weight, kg 12.8 17.5 24.3
Shipping Weight, kg 20.4 25.2 32.1
Input
Voltage Input Range (with battery
operation)
0 to 300 VAC
Voltage Input Range (without
battery operation)
144 to 290 VAC
Input Voltage Measurement
Tolerance
±5%
Nominal Voltage Setting 200 / 208 / 220 / 230 / 240 VAC
High Line Buck to Battery 241 / 251 / 266 / 278 / 290 VAC
High Line Battery to Buck 235 / 245 / 260 / 272 / 284 VAC
High Line Normalto Buck 220 / 229 / 242 / 253 / 264 VAC
High Line Buck to Normal 215 / 224 / 237 / 248 / 259 VAC
Low Line Boost1 to Normal 185 / 192 / 203 / 212 / 221 VAC
Low Line Normalto Boost1 180 / 187 / 198 / 207 / 216 VAC
Low Line Boost2 to Boost1 160 / 166 / 176 / 183 / 191 VAC
Low Line Boost1 to Boost2 155 / 161 / 171 / 178 / 186 VAC
Low Line Battery to Boost2 155 / 161 / 171 / 178 / 186 VAC
Low Line Boost2 to Battery 144 / 150 / 158 / 166 / 173 VAC
Frequency Input Range
45 to 65 Hz
Autodetect 50 / 60 Hz
Battery to Normalcomeback at 50Hz: 47 to 53Hz
Battery to Normalcomeback at 60Hz: 57 to 63Hz
Internal Rear-panel Input Breaker
Rating
10 A 16 A
Input Surge Protection EN61000-4-5; Line to Line: Level 2; Line to Earth: Level 3 (624J L/N, 624J L/G, 624J N/G)
Input Power Receptacle IEC 320 C14 IEC 320 C20
Table 6.4 Specifications, EDGELI-1500IRT2U, EDGELI-2200IRT2U, EDGELI-3000IRT2U
6 Specifications
51
Liebert® EDGE Installer/User Guide
