Vertiv Liebert HPM User Manual

Installation drawings
C --- 6Liebert HPM --- A/W/F/D/H
English
F i g . 1 3 --- N e w a i r m o d u l e
1
2
Flexible tube
UNDER / DISPLACEMENT
1
OVER / CONSTANT
Mmodelsonly
Flexible tube passage
Liebert H PM S0F ... 2G
Liebert HPM M2H ... 7L
Liebert H PM L8F --- 9H
MODELS
Dimensions (mm)
A B C
S0F 185 310 320
S 0 H --- 1 A --- 1 D 375 190 420
S 1 E --- 1 G --- 2 E --- 2 G 155 450 660
M 2 H --- 3 A 650 565 145
M3F ... 7L 225 565 145
