iPM 200 generator module
® Vetaphone March 2021 3401201GB
Page 12 of 52
iPM200 (X8/X9, FieldBus)
Optional for CAN or Profi bus, see separate documentation.
iPM200 (X22, 24Vdc Output)
Terminal number 1 & 2
+24V
Terminal number 3 & 4
GND
Max. output current
1.1Adc
Mechanical dimension (iPM200 generator module)
Length
440 mm
Width
260 mm
Height
202 mm
Weight
15.9 kg
Ambient conditions
Enclosure
IP20
Altitude
< 2000m
Max. relative humidity
5% - 85% during
operation
Ambient temperature, during operation
Max. 40°C
24-hour average max.
40°C
Min. ambient temperature during full-scale operation
0 °C
Temperature during storage/transport
0 °C to +65°C
EMC standards used, Emission
EN55011 (2007) +A2
Group 2, Class A (EDM).
EMC standards used, immunity
EN61000-6-2 (2005),
EN61000-6-4 (2007)
