iPM 200 generator module
® Vetaphone March 2021 3401201GB
Page 11 of 52
Digital input
Number of programmable digital inputs Type 2
6
Block wise configurable as
NPN or PNP
Terminal numbers
9, 10, 11, 12, 13, 14
Voltage level, logic ‘1’
> 10 V
Voltage level, logic ‘0’
< 4.5 V
Max. voltage on input
30 VDC
Communication
Terminal number 7
RS485, signal A
Terminal number 8
RS485, signal B
Digital output
Number of digital output Type 3
8
Terminal numbers
16, 17, 18, 19, 20, 21,
22, 23
Open drain outputs with no reverse voltage protection
Voltage
0 to 30 V DC
Current load max
0,5 ADC
iPM200 (X6, RS485)
Terminal number 1, 2, 9, 10
Supply ground
Terminal number 3 & 4
Supply output, 24 V DC
Terminal number 5 & 6
RS485, signal A
Terminal number 7 & 8
RS485, signal B
Max. supply output voltage
Supply output, 24 VDC
Max. output current at supply output
400 mA
iPM200 (X7, Feedback)
Terminal number 1
Feedback input, signal B
Terminal number 2
Feedback input, signal A
Terminal number 3, 4
Not connected
Terminal number 5
Peak detection input, signal B
Terminal number 7
Peak detection input, signal A
Terminal number 6, 8
CHASSIS/SCREEN
