iPM 200 generator module
® Vetaphone March 2021 3401201GB
Page 9 of 52
iPM200 (X1)
USB_B
Only connect standard USB devices
iPM200 (X2)
USB_A
Only connect standard USB devices
iPM200 (X3, Customer I/O)
Terminal number 1, 2
Interlock 2 connection
For Interlock use only potential free contacts!
Terminal number 19
24 VDC Backup input
Terminal number 20
GND
Digital Inputs
Number of digital inputs Type 1
5
Configurable as
NPN, PNP
Terminal number Positive +
3, 5, 7, 9, 11
Terminal number Negative -
4, 6, 8, 10, 12
Voltage level, logic ‘1’
> 10 V DC
Voltage level, logic ‘0’
< 4,5 V DC
Input impedance
> 4,4 kOhm
Maximum input voltage
30 V DC
Digital inputs and outputs are galvanic isolated from the onboard circuit.
Digital Outputs
Number of digital outputs Type 2
3 Open collector outputs
Terminal number Collector
14, 16, 18
Terminal number Emitter
13, 15, 17
Useable for both
NPN e PNP
Max. voltage
30 V DC
Max. current
25 mA
Digital inputs and outputs are galvanic isolated from the onboard circuit.
