Check that the nominal camshaft cam lift corresponds to the rec-
ommended gures; if not, replace the worn camshaft/s.
Nominal inlet/exhaust cam lift = 8.00 mm
Check that the diameter of the camshaft supports corresponds to
the recommended gures; if not, replace the cylinder head.
Diameter of inlet and exhaust shaft supports VF4
Diameter I support• = 43.646 ÷ 43.671
Diameter II support• = 43.446 ÷ 43.471
Diameter III support• = 43.246 ÷ 43.271
Diameter VI support• = 43.046 ÷ 43.071
Diameter V support• = 30.045 ÷ 30.070
Diameter of inlet and exhaust shaft supports VF5
Diameter I support• = 43.846 ÷ 43.871
Diameter II support• = 43.646 ÷ 43.671
Diameter III support• = 43.446 ÷ 43.471
Diameter IV support• = 43.246 ÷ 43.271
Diameter V support• = 43.046 ÷ 43.071
Diameter VI support• = 30.045 ÷ 30.070
