Pressure pump support VF54.15
Position the pressure pimp support in a vice tted with protective
jaws.
Lock the rotation of the pressure pump drive pulley using two
bolts.
Undo the pressure pump drive pulley nut.
Undo the two bolts for locking the rotation of the pressure pump
drive pulley tted previously.
Remove the pressure pump drive pulley (1 a) using the tools (1b
extractor).
