Pressure relief sensor4.10
Make sure that the ignition key is it in the OFF position, then dis-
connect the battery terminal (-).
Undo bolts (2 a) and remove the pressure relief sensor (2b).
Position the excess pressure sensor (1 a) in its housing and secure
it tightening the bolt(1b) to the recommended torque.
Excess pressure sensor
Bolt M ... (daNm) 0.9
Connect the electrical connection for the pressure relief sensor.
Connect the negative (-) battery terminal.
