Camshaft housing.4.1.3
Position the camshaft housing in the vice using the tool (sup-
port).
Tighten the engine oil lubrication duct plugs.
Place the camshaft gears in their housings.
Place the camshaft gears in their housings and secure them with-
out tightening the bolts.
Fit the camshaft timing tools (template)
Check that the tools are correctly tted in the housings in the
camshaft.
Tighten the camshaft gear xing bolts to the recommended
torque.
Camshaft gears
Bolt M12 (da Nm) camshaft side 2.9 ÷ 3.2 + 40°
