Fit the exhaust side camshaft front oil seal (1 a) using the tool (1b
tting tool).
Fit the intake side camshaft plug.
Ret the exhaust side camshaft toothed pulley and secure by
screwing in the bolt without tightening.
Position the cam angle sensor (1 a) in its housing and secure it
tightening the bolt (1b) to the recommended torque .
Cam angle sensor
Bolt M6 (da Nm) 0,8 ÷ 1,0
