Crankshaft4.2
Undo bolts (1 a) and remove oil intake duct (1b).
Fit the tool for rotating the crankshaft (ange)
Undo bolt (anti-clockwise) (1 a) and remove toothed drive pulley
(1b).
Undo bolts (2 a) and remove crankshaft front oil seal cover with
built-in oil pump (2b).
Remove the gasket.
Undo bolt (3 a) and remove timing belt xed tensioner (3b).
Undo bolt (4 a) and remove timing belt tensioners mounting (4b)
