Vetus VF4 - Engine Rpm Sensor

68 402102.01
Service manual VF4 VF5
Engine rpm sensor4.11
Make sure that the ignition key is in the OFF position, then discon-
nect the battery terminal (-).
Disconnect the electrical connection from the engine rpm sensor
(1).
Undo the bolt (2 a) and remove the rpm sensor (2b).
Position the engine rpm sensor (1 a) in its housing and secure it
tightening the bolt (1b) to the recommended torque .
Rpm sensor
Bolt M6 (daNm) 0.6 ÷ 1.0 (engine block side)
Connect the electrical connection for the engine rpm sensor.
Connect the negative battery terminal (-) .
