If the cylinder bore measurements are not within the recommend-
ed limits, ream the cylinder bores following the recommended
oversize.
If reaming, ensure all the bores have the same oversize.
Cylinder liner bore diameter oversize
0.1 mm
Fit the bearing caps.
The bearing caps have progressive references (from zero to
ve VF4, or zero to six VF5, starting from the timing system
side) which dene the tting position.
Tighten bearing cap bolts (1 a) to the recommended torque, use
torque wrench (1b).
Bearing caps
Bolt M12 (da Nm) 2.4 ÷ 2.6 + 100°
Check that the diameter of the main journal seats is within speci-
ed limits.
Main journal seat diameter
63.705 ÷ 63.718 mm
