402102.01 5
Service manual VF4 VF5
VF5.220E VF5.250E
Cycle Diesel 4 stroke
Valve gear
With 2 camshaft on the cylinder
head
Fuel system Direct injection common rail
Number of cylinder 5 in line 5 in line
∅
Bore mm 82 82
Stroke mm 90.4 90.4
+ + + . . . =
Total displacement cm
3
2387 2387
+
= CR
Compression ratio 18 : 1 18 : 1
Maximum output CEE
kW (CEE) 162 184
hp (CEE) 220 250
1/min 4200 4200
Maximum torque CEE
Nm (CEE) 401 454
kgm (CEE) 40.1 45.4
1/min 2400 2600
