Vetus VF4 - Page 71

402102.01 71
Service manual VF4 VF5
Loosen the collar on the sleeve the engine oil return pipe, turbo-
charger side.
Undo the nuts securing the turbocharger on the exhaust mani-
fold.
Remove the gasket.
Undo connector (1 a) and remove turbocharger engine oil supply
pipe (1b).
Undo bolts (2 a) and remove turbocharger oil return pipe (2b).
