VIA694X System Board 5
● Electrical--- Typical power supply
Below is reference for ATX case requirement on power supply.
Current
Voltage Tolerance
230W 250W 300W
+5V
± 5%
23A 25A 30A
+3.3V
± 5%
14A 14A 14A
+12V
±10%
9A 10A 12A
-5V
± 5%
0.5A 0.5A 0.5A
-12V
± 5%
0.8A 0.8A 0.8A
+5VSB
± 5%
1A 1A 1A
WOL (Wake up on LAN) function requirement:
Power supply should offer at lest 1A to the signal “5VSB”to support WOL function.
● Special features
• Wake up on LAN (ATX power supply is required)
• Modem ring on
• Windows 95/98/2000 power off (ATX power supply is required)
• AMR
