VIA694X System Board 3
1-2 Specifications
● PCB board size : 30.5 cm x 19.00 cm
● PCB layer : 4 layers
● Socket 370
Support Intel® Celeron CPU at 66/100 MHz F.S.B and FC-PGA Pentium III
CPU at 100 MHz/133 MHz F.S.B. , Cyrix III CPU
CPU is not enclosed in the package.
● Memory DIMM : 3 of 168-pin 3.3V DIMM
● Expansion Slot :, 5 x PCI slots, 1x A.G.P. slot and 1 x AMR( allows primary
card only)
Supports 1X/2X/4X AGP mode.
● Chipset
• VIA VT82C694X
• VIA VT82C686A
● BIOS: flash ROM for BIOS
Award® full PnP (Plug & Play) BIOS
● I/O function
• 2 x PCI IDE devices
• 1 x FDC, 2 x serial ports(16550 fast com)
• 1 x parallel port device /EPP/ECP/SPP
• 2 x USB connector (4 port, 2 port optional)
• IrDA (infrared) connector
