VIA694X System Board 20
2-3-4 CPU Fan Connectors
There are 2 fan connectors on this main board, and it is marked as “FAN1”,
“FAN2”. Each fan connector has three pins.
Fan Signal
SENSE
+12V
GND
FAN1
FAN2
