VIA694X System Board 23
2-3-7 IDE1 & IDE2
IDE1 and IDE2 are 40-pin IDE connectors. There are 2 IDE connectors
supported on this system board. IDE1 is primary channel, and IDE2 is secondary
channel. Each channel supports 2 IDE devices, and 4 devices in total for this main
board. It also supports Ultra DMA33/66 function.
IDE2
IDE1
