VIA694X System Board 14
2-2-5 JP8、JP3：Over-clocking Setup
JP8 is a 2-pin over-clocking jumper which allows 66MHz F.S.B. CPUs to
over-clock to 100MHz. This jumper is for internal test only. No guarantee is
provided for over-clocking setup since the chipset does not support.
JP3
：
is a 2-pin over- clocking jumper which allows 100MHz F.S.B. CPUs to
over-clock to 133MHz
Normal
Over-clocking 66MHz
to 100MHz
Over-clocking 100MHz
to 133MHz
JP8 ON OFF ON
JP3 ON ON OFF
The manufacturer shall have neither liability nor responsibility to any person
or entity with respect to any loss or damages arising by users’ over-clocking or
over-voltage.
JP3,JP8:Over-clocking Setup
Normal
Over-clocking
JP3
JP8
To Next Page
