VIA694X System Board 11
2-2-3 VID0-VID4 : CPU Vcore Selector
VID0-VID4 are 3-pin connectors which provides CPU Vcore selection. Please
select the right Vcore according to your CPU and set details as below.
VID0-VID4 :CPU
Vcore Selector
VID0
VID1 VID2
VID3 VID4
VID0-VID3 VID4
Default(1-2) Default(2-3) : for Socket370 Intel
PII/PIII CPU, Cyrix III CPU
VID0 VID1 VID2 VID3 VID4 CPU_Volt.
2-3 1-2 1-2 2-3 1-2
2.9V
1-2 1-2 1-2 2-3 1-2
2.8V
