VIA Technologies VT82C694X Pro - Page 18

VIA694X System Board 12
2-3 2-3 2-3 1-2 1-2
2.7V
1-2 2-3 2-3 1-2 1-2
2.6V
2-3 1-2 2-3 1-2 1-2
2.5V
1-2 1-2 2-3 1-2 1-2
2.4V
2-3 2-3 1-2 1-2 1-2
2.3V
1-2 2-3 1-2 1-2 1-2
2.2V
2-3 1-2 1-2 1-2 1-2
2.1V
1-2 1-2 1-2 1-2 1-2
2.0V
2-3 2-3 2-3 2-3 2-3
2.05V
1-2 2-3 2-3 2-3 2-3
2.00V
2-3 1-2 2-3 2-3 2-3
1.95V
1-2 1-2 2-3 2-3 2-3
1.90V
2-3 2-3 1-2 2-3 2-3
1.85V
1-2 2-3 1-2 2-3 2-3
1.80V
2-3 1-2 1-2 2-3 2-3
1.75V
1-2 1-2 1-2 2-3 2-3
1.70V
2-3 2-3 2-3 1-2 2-3
1.65V
1-2 2-3 2-3 1-2 2-3
1.60V
2-3 1-2 2-3 1-2 2-3
1.55V
1-2 1-2 2-3 1-2 2-3
1.50V
2-3 2-3 1-2 1-2 2-3
1.45V
1-2 2-3 1-2 1-2 2-3
1.40V
2-3 1-2 1-2 1-2 2-3
1.35V
1-2 1-2 1-2 1-2 2-3
1.30V
Please don’t change default setting. The manufacturer shall have neither
liability nor responsibility to any person or entity with respect to any loss or
damages arising by users’ over-clocking or over-voltage.
