VIA694X System Board 10
2-2-2 JP1 : CPU Type Selector
JP1 is 2-pin connector, which provides to select CPU type.
JP1:CPU Type Selector
CPU Type JP1
INTEL FC-PGA PIII CPU CLOSE
Cyrix III CPU OPEN
INTEL PII Celeron CPU OPEN
Remarks : JP1 : FC-PGA Coppermine/Celeron/Cyrix selector.
