VIA694X System Board 17
2-3-2 Back Panel
There are keyboard/mouse, USB1/USB2, COM1/2, LPT1, port on the case back
panel. Please refer to more details as below.
KBMS1
USB1
COM1 COM2
LPT1
USB2
