VIA694X System Board 43
Onboard Serial Port 1/Port 2
:3F8/IRQ4
:2F8/IRQ3
:3E8/IRQ4
:2E8/IRQ3
:Auto (default)
:Disabled
UART 2 Mode
:Standard (default) --- the user is not allowed to modify “IR Function Duplex,”
and “TX, RX inverting enable.”
:ASKIR --- the user is allowed to modify “IR Function Duplex,” and “TX, RX
inverting enable.”
:HPSIR --- the user is allowed to modify “IR Function Duplex,” and “TX, RX
inverting enable.”
Onboard Parallel Port
:378/IRQ7 (default)
:278H/IRQ5
:3BC/IRQ7
:Disabled
Onboard Parallel Mode
:Normal (default)
:ECP, EPP, ECP/EPP
ECP Mode Use DMA
Select a DMA channel for the parallel port for use during ECP mode.
:3 (default)
:1
Parallel Port EPP Type
This item allows you to determine the IR transfer mode of onboard I/O chip.
:EPP1.9 (default)
:EPP1.7
